Model

OS-20N7

Image Sensor

1/4" Sharp color CCD

Pixels

PAL: 537(H)×597(V) NTSC: 537(H)×505(V)

Resolution

420TVL

Minimum Illumination

1.0LUX

S/N Ratio

>48dB

Electronic Shutter

NTSC:1/60-1/100,000 second PAL:1/50-1/100,000 Second

Lens

Board mount Lens: 3.7mm

Video Output

1.0Vp-p,75Ω,Composite

AGC

AUTO

AWB

AUTO

Scanning system

2:1 Internal

S/N Ratio

＞48dB

Gamma

0.45

Sync system

Internal

Voltage

12VDC

Wattage

1.5W

Working Environment

Temperature:10℃ to 50℃

Humidity:<90%RH

Size

90x62mm
