Models |
DVR408 DVD |
Video Format |
NTSC/PAL |
Video Compression |
MJPEG |
Internet Transmitting / Compression |
MPEG4 |
Display Frame Rate |
240/200fps |
Recording Frame Rate (Auto balance) |
60/50fps |
Display Resolution |
640x448 / 640x544 |
Recording Resolution |
640x224/640x272 |
Display Division |
Single / Sequence / Split (1/4/8) |
Video Input |
BNCx8 |
Video Output |
Video outx2, S-Videox1, VGAx1 |
Audio In/Out |
1/1 |
Alarm In/Out |
8/1 |
Recording Mode |
Continuous / Schedule / Motion Detection / Sensor |
Recording Quality |
High/Normal/Low |
Search Mode |
Time/Event |
Storage Support |
DVD-RW x 1 + SATA HDD X 1 or SATA HDD x 2 (Internal) |
Backup Device |
USB stick / DVD±RW |
Serial Connectors |
USB 2.0x1, Mouse (Combo USB & PS/2 protocol) x 1,
RS485 x 1 |
Network Connection |
10/100 Ethernet(RJ-45) |
Network Protocol |
TCP/IP, Static IP, DHCP, PPPOE , DDNS
(through Router) |
Network Remote |
Remote monitoring, recording, playback
and PTZ by Client Program and IE browser. |
Power Supply |
Input:AC100~240V, 50/60Hz
Output:DC12V/5A |
Dimension(WxHxD) |
340X60X280mm |
Weight |
3kg (W/O HDD) |
