| Model |
704 |
| Video Format |
NTSC/PAL |
| Video Compression |
H.264 |
| Display Frame Rate |
120/100fps |
| Display Resolution |
720x480(NTSC) / 720x576(PAL) |
| Recording Resolution |
Half D1: 720x240(NTSC) / 720x288(PAL)
CIF:.360x240(NTSC) / 360x288(PAL) |
Recording Rate
(Half D1) |
NTSC: 720x240 / 60PPS
PAL: 720x288 / 50PPS |
Recording Rate
(CIF) |
NTSC: 360x240 / 120PPS
PAL: 360x288 / 100PPS |
| Recording Mode |
Manual/ Schedule |
| Display Division |
1/4 |
| Video Input |
BNCx4 |
| Video Output |
Video outx1, VGAx1 |
| Audio In/Out |
1/1 |
| Alarm In/Out |
4/1 |
| Motion Detection |
YES |
| Search Mode |
Time/Event |
| Storage Support |
SATA HDDx1 |
| Backup Device |
USB stick |
| Backup Speed |
Fast Forward 2X/4X/6X
Fast Backward 2X/4X/6X
Field by field Playback |
| Serial Connectors |
USB port for Backup x1, USB port for Mousex1,
RS485x1, IR receiverx1 |
| Network |
10/100 Ethernet(RJ-45) |
| Network Protocol |
TCP/IP, Static IP, DHCP, PPPoE, DDNS |
| Network Remote |
Remote monitoring, recording, playback and IE browser. |
| Remote Client |
YES (Available for 4 clients at the same time) |
| OSD & setup |
Daylight Saving Time, Video Loss Detection,
Authentication Management, |
| PTZ Control (RS485) |
| Firmware Upgrade |
USB / Network |
| Multi-Language |
YES |
| Power Supply |
Input:AC100~240V 50/60Hz,
Output:DC12V |
| Dimension(WxHxD) |
340X60X270mm |
| Weight |
3kg(W/O HDD) |
|
